The main purpose of this assignment is to develop an efficient doubly-linked circular list from scratch in C.

Electronic submissions only.

For the first part of the assignment, you need to implement a doubly-linked circular list. You need to create "my402list.c" to work with "my402list.h". You would also need "cs402.h". You must not alter the files provided on this web page. For the meaning of the functions, please see function definition below. After you have successfully implemented the doubly-linked circular list, you must use it to implement the sort command specified below.

We will not go over the lecture slides for this assignment in class. Although it's important that you are familiar with it. Please read it over. If you have questions, please e-mail the instructor.

    make warmup1

    warmup1 sort [tfile]

The meaning of the commands are:

sort

:

Produce a sorted transaction history for the transaction records in tfile (or stdin) and compute balances. The input file should be in the tfile format.

The output for various commands are as follows.

sort

:

Your job is to read in a tfile one line at a time. For each line, you need to check if it has the correct format. If the line is malformed, you should print an error message and quit your program. Otherwise, you should convert the line into an internal object/data structure, and insert the object/data structure into a list, sorted by the timestamp. If there is another object/data structure with identical timestamp, you should print an error message and quit your program.

After all the input lines are processed, you should output all the transactions in ascending order, according to their timestamps. The output must conform to the following format (please do not print the first 3 lines below, they are only for illustration purposes):

    00000000011111111112222222222333333333344444444445555555555666666666677777777778
    12345678901234567890123456789012345678901234567890123456789012345678901234567890

    +-----------------+--------------------------+----------------+----------------+
    |       Date      | Description              |         Amount |        Balance |
    +-----------------+--------------------------+----------------+----------------+
    | Thu Aug 21 2008 | Initial deposit          |      1,723.00  |      1,723.00  |
    | Thu Jan  1 2009 | Phone bill               | (       45.33) |      1,677.67  |
    | Mon Jul 13 2009 | Dear parents             |     10,388.07  |     12,065.74  |
    | Sun Jan 10 2010 | Beemer monthly payment - | (      654.32) |     11,411.42  |
    +-----------------+--------------------------+----------------+----------------+

Each line is exactly 80 characters long (followed by a single "\n" character). The Date field spans characters 3 through 17. Please use ctime() to format the timestamp and remove unnecessary characters to make it look like what's in the table above. (If you don't want to use ctime() and would prefer to use something else, you need to make sure that your printout is 100% compatible with ctime(). For more information, please do a string search for "ctime" in the Warmup 1 FAQ.) The Description field (shown as "..." above to mean whatever that's appropriate) spans characters 21 through 44. (If a description is too long, you must truncate it to the right length, please see the sample printout and grading guidelines for examples.) The Amount field spans characters 48 through 61. It must contain a decimal point with at least one digit to the left of the decimal point and exactly two digits to the right of the decimal point. If the number to the left of the decimal point is not 0, the first digit of this number must not be a 0. For a withdrawal, a pair of paranthesis must be used as indicated. If the amount of a transaction is more than or equal to 10 million, please print ?,???,???.?? (or (?,???,???.??)) in the Amount field to indicate that the amount is too large to fit in the display area. The Balance field spans characters 65 through 78. If a balance is negative, a pair of paranthesis must be used. If the absolute value of a balance is more than or equal to 10 million, please print ?,???,???.?? (or (?,???,???.??)) in the Balance field to indicate that the balance is too large to fit in the display area.

The functions you need to implement has the following meaning (note that, for readability, all the functions are missing "My402List" before the name, and all of them are missing (My402List*) as the first argument as compare to what's in the actual header file, "my402list.h"; furthermore, other than the Init() function, you must assume that for all other functions, the first argument is a valid list; for the Init() function, you must assume that the first argument points to sizeof(My402List) bytes of valid memory):

int Length()

Returns the number of elements in the list.

int Empty()

Returns TRUE if the list is empty. Returns FALSE otherwise.

int Append(void *obj)

Use malloc() to create a new list element (of type My402ListElem) and copy obj into the obj field of the newly created list element. If list is empty, just add the newly created list element to the list. Otherwise, add the newly created list element after Last(). This function returns TRUE if the operation is performed successfully and returns FALSE otherwise.

int Prepend(void *obj)

Use malloc() to create a new list element (of type My402ListElem) and copy obj into the obj field of the newly created list element. If list is empty, just add the newly created list element to the list. Otherwise, add the newly created list element before First(). This function returns TRUE if the operation is performed successfully and returns FALSE otherwise.

void Unlink(My402ListElem *elem)

Unlink and free() elem from the list. Please do not free() the object pointed to by elem and do not check if elem is on the list.

void UnlinkAll()

Unlink and free() all elements from the list and make the list empty. Please do not free() the objects pointed to by the list elements.

int InsertBefore(void *obj, My402ListElem *elem)

Use malloc() to create a new list element (of type My402ListElem) and copy obj into the obj field of the newly created list element. Insert the newly created list element between elem and elem->prev. If elem is NULL, then this is the same as Prepend(). This function returns TRUE if the operation is performed successfully and returns FALSE otherwise. Please do not check if elem is on the list.

int InsertAfter(void *obj, My402ListElem *elem)

Use malloc() to create a new list element (of type My402ListElem) and copy obj into the obj field of the newly created list element. Insert the newly created list element between elem and elem->next. If elem is NULL, then this is the same as Append(). This function returns TRUE if the operation is performed successfully and returns FALSE otherwise. Please do not check if elem is on the list.

My402ListElem *First()

Returns the first list element or NULL if the list is empty.

My402ListElem *Last()

Returns the last list element or NULL if the list is empty.

My402ListElem *Next(My402ListElem *elem)

Returns elem->next or NULL if elem is the last item on the list. Please do not check if elem is on the list.

My402ListElem *Prev(My402ListElem *elem)

Returns elem->prev or NULL if elem is the first item on the list. Please do not check if elem is on the list.

My402ListElem *Find(void *obj)

Returns the list element elem such that elem->obj == obj. Returns NULL if no such element can be found.

int Init()

Initialize the list into an empty list. Returns TRUE if all is well and returns FALSE if there is an error initializing the list.

    void Traverse(My402List *list)
    {
        My402ListElem *elem=NULL;

        for (elem=My402ListFirst(list);
                elem != NULL;
                elem=My402ListNext(list, elem)) {
            Foo *foo=(Foo*)(elem->obj);

            /* access foo here */
        }
    }

If you are not familiar with pointers in C, please take a look at my review on pointers.

• Transaction type (single character: "+" for deposit or "-" for withdrawal).
• Transaction time (a UNIX timestamp, please see man -s 2 time on your 32-bit Ubuntu 16.04 system). The value of this field must be > 0 and < the timestamp that correspond to the current time. Also, since this is a number, the first digit must not be zero. (Since the largest unsigned integer is 4,294,967,295, if the length of the string of this field is more than or equal to 11, you can safely assume that the timestamp is bad.)
• Transaction amount (a number followed by a period followed by two digits; if the number is not zero, its first digit must not be zero; if the number is zero, its length must be 1). The number to the left of the decimal point can be at most 7 digits (i.e., < 10,000,000). The transaction amount must have a positive value.
• Transaction description (textual description, cannot be empty). A description may contain leading space characters, but you must remove them before proceeding. After leading space characters have been removed, a transaction description must not be empty.

If you encounter an error when you process the input file, you should print an error message and quit your program. You must not process additional input lines. Please also note that a valid file must contain at least one transaction.

A sample tfile is provided here as test.tfile.

• listtest.c
• Makefile

If you do:

./listtest

./listtest -debug

    ./warmup1 sort test.tfile

    +-----------------+--------------------------+----------------+----------------+
    |       Date      | Description              |         Amount |        Balance |
    +-----------------+--------------------------+----------------+----------------+
    | Thu Aug 21 2008 | Initial deposit          |      1,723.00  |      1,723.00  |
    | Thu Jan  1 2009 | Phone bill               | (       45.33) |      1,677.67  |
    | Mon Jul 13 2009 | Dear parents             |     10,388.07  |     12,065.74  |
    | Sun Jan 10 2010 | Beemer monthly payment - | (      654.32) |     11,411.42  |
    +-----------------+--------------------------+----------------+----------------+

The grading guidelines is the only grading procedure we will use to grade your program. No other grading procedure will be used. To the best of our effort, we will only change the testing data for grading but not the commands. (We may make minor changes if we discover bugs in the script or things that we forgot to test.) It is strongly recommended that you run your code through the scripts in the grading guidelines.

A copy of the grading scripts are made available here (the .out files are what the output suppose to look like):

    section-A.csh        section-A.out
    section-B.csh        section-B.out

    chmod 755 section-?.csh

By the way, please do not run these grading scripts in a shared folder. For unknown reasons, running the grading scripts from within a shared folder may not work correctly!

• Please read the general programming FAQ if you need a refresher on file I/O and bit/byte manipulications in C.

• You must NOT use any external code segments to implement this assignment. You must implement all these functionalities from scratch.

• You must not use any arrays to implement list functionalities. You must dynamically allocate all elements in a list.

• For the sort command, you must use the doubly-linked circular list developed in this assignment.

• If the size of the input file is large, you must not read the whole file into a large memory buffer and then process the file data. You must read the file incrementally.

• One of the purposes of this warming assignment is to get you up to speed with programming in C. It's important that every byte of your data is read and written correctly. You will lose a lot of points if one byte of data is generated incorrectly! To make sure that your printout is perfect, please run your code through the grading guidelines since following the grading guidelines is the only way the grader can grade.

• Please follow the UNIX convention that, when your output is an ASCII file (such as the output of the sort command), append '\n' in the last line of the output if it's not a blank line. (This way, you don't get the commandline prompt appearing at the wrong place on the screen.)

• String I/O functions such as fgets(), scanf(), and printf() are really meant for inputing/outputing strings. Do not use them to input/output binary data! Do not use them to input/output binary data (unless you are sure what you are doing)!

• Start working on this early! Please don't complain to the instructor that this assignment is too tedious or it takes too much work just to parse the commandline. Get it done early and get it done right!

    tar cvzf warmup1.tar.gz MYLISTOFFILES
    ls -l warmup1.tar.gz

Please note that the 2nd commandline argument of the tar command above is the output filename of the tar command. So, if you omit warmup1.tar.gz above, you may accidentally replace one of your files with the output of the tar command and there is no way to recover the lost file (unless you have made a backup copy). So, please make sure that the first commandline argument is cvzf and the 2nd commandline argument is warmup1.tar.gz.

A w1-README.txt template file is provided here. You must save it as your w1-README.txt file and follow the instructions in it to fill it out with appropriate information and include it in your submission. You must not delete a single line from w1-README.txt. Please make sure that you satisfy all the README requirements.

Here is an example commands for creating your warmup1.tar.gz file:

    tar cvzf warmup1.tar.gz Makefile *.c *.h w1-README.txt

If you use an IDE, you need to modify the commands above so that you include ALL the necessary source files and subdirectories and make sure you have not forgotten to include a necessary file in order for the grader to compile your code on a "clean" system.

You should read the output of the above commands carefully to make sure that warmup1.tar.gz is created properly. If you don't understand the output of the above commands, you need to learn how to read it! It's your responsibility to ensure that warmup1.tar.gz is created properly.

To check the content of warmup1.tar.gz, you can use the following command:

    tar tvzf warmup1.tar.gz

Please enter your USC e-mail address and your submission PIN below. Then click on the Browse button and locate and select your submission file (i.e., warmup1.tar.gz). Then click on the Upload button to submit your warmup1.tar.gz. (Be careful what you click! Do NOT submit the wrong file!) If you see an error message, please read the dialogbox carefully and fix what needs to be fixed and repeat the procedure. If you don't know your submission PIN, please visit this web site to have your PIN e-mailed to your USC e-mail address.

When this web page was last loaded, the time at the submission server (merlot.usc.edu) was 27Nov2025-17:24:06. Reload this web page to see the current time on merlot.usc.edu.

It is extreme important that you also verify your submission after you have submitted warmup1.tar.gz electronically to make sure that every you have submitted is everything you wanted us to grade. If you don't verify your submission and you ended up submit the wrong files, please understand that due to our fairness policy, there's absolutely nothing we can do.

Finally, please be familiar with the Electronic Submission Guidelines and information on the bsubmit web page.
